Key Features
- Dual Test Module System
- Tests up to 3000 Ends / Hour / Module
- True Micro Leak Test (3×10-6 cc/sec)
- Automatic Reject Logging & Ejection
- Self-Diagnostics
- No Operator Judgment Required
- Fully Automatic Operation
- Low Maintenance
- Automatic Calibration Check
- PLC Controlled
- Results on Local Colour Display
- Optional PC Data Collection
| Leak Ranges | |
|---|---|
| Gross Leak | > 1 Atms. cc/sec. |
| Medium Leak | 1 to 0.05 Atms. cc/sec. |
| Micro Leak | 0.05 to 0.000003 Atms. cc/sec. |
| Test Modules | |
| Throughput | Up to 3000 ends / hour per module |
| Feed Chute | Holds up to 600 ends per module |
| End Size | All standard end sizes |
| Services Required | |
| Power | 380–415v, 6 amps, 50/60Hz – Single and 3-phase required |
| Compressed Air | Dry Air @ 6 Bar |
| Helium | Helium @ 2 Bar |
| Dimensions | |
| Overall | 260cm(L) × 100cm(W) × 175cm(H) |
